Name/TitleWagon jack

About this objectThis black and red wagon jack as a rectangular base, a central column, and a lipting arm, with a chain attached to both base and column. At the top of the column is a slit and two upward projections which support an axel which pierces the arm near one end, supporting it and permitting a restrained up and down movement. The arm at the short end has a covering of iron, and at the long end is shared as a handle. The column is pierced with a pin to which one end of the chain is attached.

Medium and MaterialsAxel: iron
Chain: iron
Cover of short end: iron
Pin: non-ferrous metal
Remainder: wood

MeasurementsBase length: 84mm
Base breadth: 38mm
Base depth: 9mm
Overall length: 160mm
Column length: 32mm
Column breadth: 28mm
Column height: 45mm
Overall height: 65mm
Arm short end length: 34mm
Arm long end length: 124mm
Total length: 158mm
Breadth: 3mm
Depth: 11mm

Object numberSTMEA:1999-68.9
