Name/TitleModel - Plough

About this objectA model of a Newcastle (?) plough with a beam, mainly horizontal but curving to the ground at the rear and then forward to support on the right side the mould board and shape. The beam is supported near the front by two wheels of different sizes (each with scraper), the larger being on the right. A coulter projects downward from above the beam on the left. A pair of handles project upwards and backwards from the beam. A small projection in front carries a chain with three links.

Medium and MaterialsHandles: Wood
Beam: Wood and Iron
Mould board, shape, coulter and front projection: Iron
Wheels: Brass

MeasurementsOverall length: 720 mm
Maximum height: 240 mm
Minimum height: 104 mm

Handles:
L: 330 mm
B: 160 mm
H: 225 mm

Beam:
L: 360 mm
H: 130 mm

Wheel hubs: B: 125 mm
Diameter of wheels: 130 and 75 mm

Front addition length: 20 mm

Object numberSTMEA:1997-29.1
